Coliter ® Cast Steel Swing Check Valve – PN1.6~4.0, ≤425°C, Flanged Swing Design for High-Pressure Steam, Oil & Water Systems

H44H Cast Steel Swing Check Valve – Heavy-Duty Flanged Check Valve with WCB Body for Reliable Backflow Prevention in Industrial Pipelines

The Coliter® H44H Cast Steel Swing Check Valve is a robust, flanged swing-type check valve designed to automatically prevent reverse flow in high-pressure and high-temperature industrial pipelines handling steam, oil, water, and other non-corrosive media. Constructed from WCB carbon steel (standard) or optional CF8/CF8M stainless steel, it features a durable swing disc mounted on a hinge pin that opens fully under forward flow and closes by gravity when flow stops or reverses—ensuring reliable, low-torque operation with minimal pressure drop. Rated for nominal pressures from PN16 to PN40 (1.6–4.0 MPa) and operating temperatures up to 425°C, the H44H complies with international standards GB/T 12235 (design) and API 598 (testing). Available in sizes from DN25 to DN600, it uses standard flanged end connections per GB/T 9113 or ANSI B16.5. The valve’s streamlined flow path reduces turbulence, while its solid cast construction ensures long service life in demanding applications such as power generation, petrochemical plants, district heating, and boiler feed systems. Designed for horizontal or vertical (flow upward) installation, the H44H delivers maintenance-free, fail-safe backflow protection where system integrity and safety are critical.
